DC 12V 200 Amp Power Supply DC-DC Type for Telecom Security System

dc 12v 200 amp power supply

EVS Series™ 6U Rack Mount AC to DC Switching Power Supplies

Product Description:

EVS Power Series™ is a unique and a highly reliable power supply series. It can be configured as a single as well as a fully redundant power supply. EVS Power Series™ is designed for Universal AC to DC power supply applications. Because of this feature these power supplies can be used anywhere in the world. These power supplies are mainly used in the following applications:

• Computer Peripherals and Networking
• Telecommunications and Fiber optic Network
• Voice, Data and Analog Communications
• Universities and Educational Facilities
• Instrumentation and Electronics
• Utility and Power Industries
• Data Acquisition

Power Supply Main Features:

EVS Power Series is a reliable, efficient and inexpensive solution for all kind of AC to DC power supply applications.

• Compact Rack Mount Size
• Universal AC (Alternate Current) Input
• Filtered IEC AC Inlet Connectors
• EMI FCC Class B Clearance
• Single and Multiple Output
• Highly Efficient Design
• 19inch rack mount
• NO Minimum Load Required
• RS485/SNMP Remote Management
• Low Voltage Power Supply Alarm
• Data Line Alarm And ACO (Alarm Cut Off) System
• Cost Effective and Reliable Power Supply

1.Introduction

DC Power Distribution Unit is suitable to indoor low voltage DC power contribution system. Mounted in a rack cabinet and connected between the -48V DC power supply and the protected equipment, it can protect the equipment from surge and instantaneous over voltage caused by the outside environment (lightning, electromagnetic radiation interference, etc.) or by the internal subsystems (switching effect, start and stop operation of inductive and capacitive loads), it is a Class C drawer type surge protector for DC power distribution with the following features.

19 inch 6U rack installation;
output 4 outputs 12V 50A;
Circuit breaker for each of the 4 outputs ,can disconnect the circuit when fault or overload happens
Easy connection for inputs and outputs wiring;
Insulation of output connectors;
Large current discharge capability and low residual voltage;
Remote signal alarm connectors (dry contacts of remote signal alarm is closed at normal operation while open at fault condition).

2.12V power supply Configuration

2.1 Operating environment

Operating temperature:-40℃~+70℃;

Relative humidity:5%-95%;

Atmosphere pressure:70kPa~106kPa

2.2 Storage environment

Storage temperature:-40℃~+85℃;

Relative humidity:5%-95%;

Atmosphere pressure:70kPa~106kPa

Storage time limit:12months

2.3 Reference standards

GB4943.2001/IEC60950:1999
Safety of information technology equipment
GB/T18802.21-2004/IEC61643-21:2000 Low voltage surge protective device, part 21, SPD for telecommunication and signal networks-performance requirements and tests.
YD/T1542-2006
Technical requirements and test methods of SPDs for signal networks
