Hot Sale 100A 48V to 48V Professional Industrial Inverters Converters Factory Manufactured DC-DC Converter for Professional Use

EVS3U-48S12300

minimum order:

1 piece

Quantity:

$500.00 - $850.00 / piece

Contact Now

add to cart

Output Current:100 A
Output Frequency:50Hz/60Hz
Phase:Single Phase
Type:DC/DC Converters
Model Number:EVS3U-48S12300
Brand Name:OEM
Place of Origin:Guangdong, China
Application:Industrial, charge battery and use for DC loads
Efficiency:0.89
Network:SDK
Output Type:Single
Size:482*133*300(mm)
Weight:18KG
Inverter type:48v to 48v dc converter
Display:LED+LCD
Warranty:1 Year
MTBF:≥100000 hours
Customized support:Software reengineering
input:48VDC
output:48VDC

Product Description

48v to 48v dc converter

The module is designed with a high-frequency pulse width modulation technology,48V to 48V DC-DC power module: mainly used for voltage stabilization or isolation, with both input and output at 48V, suitable for communications, electricity, solar energy and other fields

Features with the following specifications

Rectifier module adopts active power factor compensation technology, power factor up to 0.99.
DC input voltage of normal operating range as wide as 40 ~ 60Vdc
Rectifier modules adopts full bridge soft switching technology, efficiency can reach above 92%.
Rectifier module adopts no damage hot insert and pull technology, replacement time less than 1min.
Complete fault protection, fault alarm function.
Comprehensive operation and maintenance, and can be mounted against the wall, saving space effectively.
Ultra-low radiation. Adopt advanced electromagnetic compatibility design, the rectifier module can meet requirements for conducted and radiated interference of"the communication power equipment electromagnetic compatibility Limits and methods of measurement"( People's Republic of China telecommunications industry standard YD/T983).
Safe and reliable. System design in full compliance with safety standards EN60950 and GB4943.

100a 48v to 48v dc-dc Input
Parameter	Min		Typical	Max		Unit	Notes
Input vol range	40		53.5	60		Vdc
Input current	0		90	120		A
Output
Parameter		Min	Typical	Max	Unit		Notes
Output voltage range		42	48	58	Vdc		adjustable by monitoring
Output current range		0		125	A
Output Power				6000	W		Output constant power and constant current protection; output current protection point (linear change with output voltage)
Output efficiency			89.5		%		53.5Vdc input
Regulation accuracy				±1	%
Load regulation rate				±1	%
Source adjustment rate				±1	%
Ripple (peak-to-peak)				±1%	within rated input voltage and load, add 0.1uF ceramic capacitor and 10uF electrolytic capacitor each at the output end, oscilloscope bandwidth 20MH

48V to 48V dc converter
Parameter	Min	Typical	Max	Unit	Notes
DC input overvoltage protection	58	60	62	Vdc	Self-healing
DC input overvoltage protection recovery				Vdc	Return difference is not less than 2V
DC input undervoltage protection	38	40	42	Vdc	Self-healing
DC input undervoltage protection is restored				Vdc	Return difference is not less than 2V
Input anti-reverse protection					Power does not turn on
Output short-circuit protection	Long short circuit				Can be short-circuited for a long time and automatically recover
