48V 3000W Wall-Mounted DC Charger for Industry 50A Output Current 500W Output Power 60Hz Frequency Single DC-DC Type 220V/110V

EVS-4850WM

minimum order:

1 piece

Quantity:

$200.00 - $300.00 / piece

Contact Now

add to cart

Input Voltage:80-300Vac / 100-400Vdc
Output Current:0-50A
Output Voltage:48V
Model Number:EVS-4850WM
Brand Name:OEM ODM
Place of Origin:Guangdong, China
Application:Industry, Laboratory, Industrial Equipment, Machines, Battery Charging
Efficiency:95%
Output Frequency:50/60 Hz
Output Type:Single
Protection:Over Power Protection, Overloading Protection, Over Temperature Protection, Overvoltage Protection, Overcurrent Protection
Type:AC-DC, 48V DC Outdoor for telecommunication cabinets
Function:Telecom base stations
Compatible Brand:Wall mounted power supply system
Logo:Can be design according to customer
Condutor:Rectifier Module
Colors:RAL7035

Product Description

This model of power supply is for commucication,
Output voltage +54V,Output current 0-50A;Its features include input over/under-voltage protection, output over-current protection, output over-voltage protection.

Product performance

EVS power supply system power supply, with the following features and functions:
1, wide voltage input range: 80 ~ 300Vac/ 100-400Vac, suitable for all countries in the world of AC power grid input;
2, the system has high power factor greater than 0.95;
3, there are input under voltage, input voltage, output voltage, output current limiting, output short circuit, over temperature protection;
4, the system with battery input interface and battery voltage management and battery charging function.

5,Ultra-low radiation. Adopt advanced electromagnetic compatibility design, the rectifier module can meet requirements for conducted and radiated interference of"the communication power equipment electromagnetic compatibility Limits and methods of measurement"( People's Republic of China telecommunications industry standard YD/T983).

Main Specifications:

ut Power	Input Voltage Range	Output Rated Voltage	Output current range	Ripple (Pk-Pk) (rated load, bandwidth 20MHz)
3000W	90—280	54Vdc	0—50A	200mV

Environmental Conditions:

No.	Items	Technical Specifications	Unit	Remarks
1	Operation Temperature	-15—+50	℃
2	Storage Temperature	-40—+85	℃
3	Relative Humidity	10—90	%
4	Cooling	Air cooling with self-fan
5	Altitude	70—106	Kpa
6	Storage Temperature	3000	M

Electrical Characteristics:

1	Input Characteristics
No.	Items			Technical Specifications			Unit				Remarks
1.1	Input rated voltage			200—240			Vac
1.2	Input voltage range			90—264			Vac
1.3	Input Current			≤8			A				Lowest input voltage, rated load
1.4	inputvoltage frequency			50/60			Hz
1.5	Power factor			≥0.99							rated input voltage, rated load
1.6	Input Shock Current			≤30			A				264Vac
2	Output Characteristics
No.	Items			Technical Requirements			Unit				Remarks
2.1	Output Rated Voltage			54			Vdc
2.2	Output current range			0—50			A				Inutpu voltage:176—264Vac.
				0—95			A				Inutpu voltage:90—175Vac
2.3	Output voltage range			53.5—54.5			Vdc
2.4	Efficiency			≥95%							220Vac input,output 54Vdc/25A.
				≥85%							110Vacinput ,output54Vdc/95A.
2.5	Output ripple & noise			≤200			mVp-p				Rated load, frequency band is limited to 20MHz
2.6	Turn-on output delay			3—8			S				Vin=220Vac
2.6	Output rising time			≤200			mS				Output voltage rises from 10% to 90%, rated load.
2.7	Turn on/off overshoot			≤±5			%Vo
2.8	Combined regulation			≤±1%
2.10	Transient Response	Overshoot		≤ ±5			%Vo				5%—50%—25% or 50%—75%—50% load change.
		Recovery time		≤ 200			µS
2.11	Phone weighed noise voltage			≤2			mV
2.12	p-pk value noise			≤400mV							0—300KHz
2.13	Wide frequency noise voltage			≤100			mV				3.4—150KHz
				≤30							0.15—30000KHz
2.14	Disperse noise			≤5			mV				3.4—150KHz
				≤3							150—200KHz
				≤2							200—500KHz
				≤1							500—30000KHz
3	Protection characteristics
No.	Items			No.			Items				No.
3.1	Output overvoltage protection			58.5—62			Vdc				Locked
3.2	Input overvoltage (0A output)			protection point	≥295		Vac				overvoltage,cut output
				protection tollerance	≥5						The power module must be restart when the input voltage recover to 264Vac.
3.3	Input undervoltage protection point			protection point	≤80		Vac				Cut output
				protection tollerance	≥5						The power module must be restart when the input voltage recover to 90Vac.
3.4	Overtemperature protection			yes							Auto-recoverat environmental temperature 50℃
3.5	Output overcurrent protection			0-50			A				220VAC Input,Auto-recoverat
				25							110VAC Input,Auto-recoverat
3.6	Output short-circuit protection			yes		No damage with short-circuit for long time;
3.7	Fan failure protection			The module operate with half-load when single fan failure(160w when 220Vac input,120w when 110Vac input),and alarm till the module turn off output because of overtemperature protection. When two fans failure, the module turn off output after alarm;
4	Battery Management Characteristics
No.	Items		Technical Requirements				Unit		Remarks
4.1	Floating charge current limiting		8.5±1.5				A
4.2	Battery undervoltage protection point		42.5—43.5				V		Cut load,protect battery
5	Other Characteristics
No.	Items		Technical Requirements					Unit		Remarks
5.1	MTBF		100,000					H
