48VDC 380VAC High Power 10000W-15000W Sine Wave Solar Inverter Battery Charger Three-Phase Single Phase Output Various
- Output Frequency:50/60 Hz
- Phase:Single Phase
- Brand Name:EVS
- Place of Origin:Guangdong, China
- Application:Industrial
- Efficiency:86%
- Network:SDK
- Output Type:Single
- Type:DC/AC Inverters
- Display:LCD+LED Display
- Product Name:48v Dc To 380v Ac Three-phase Inverter
- Output voltage waveform:Sine wave
- Transistor connection:Full-Bridge
48vdc inverter with battery charger
Features with the following specifications:
1.Pure sine wave output; do not harm electrical equipment, effective protection of the load; comes with UPS conversion function, high-speed conversion, the conversion time less than 5ms; ensure uninterrupted electricity;
2.CPU management, intelligent control, modular composition, which is more convenient for after-sale maintenance;
3.LED + LCD display, a visual display of all operating parameters of the machine, including the PV voltage and current;
4.High conversion efficiency,The conversion efficiency is 90-95% in half load situation ; more than 99% in commercial situation; low-consumption, under the save power mode,the consumption is between 1W ~ 6W;High efficiency and energy conservation.
5.Increased electricity auxiliary charging function; powerful charging function, three-stage intelligent charging for different types of batteries, such as sealed lead-acid batteries, open lead acid batteries, gel batteries, seven kinds of batteries,Note:lithium batteries need to setting as customers use specifications before the delivery.
6.Intelligent temperature control fan, more energy and longer life.
| Solar orerter parameters specifications | ||
| Power Specifications | 1000W~12KW | |
| DC Input Specifications | ||
| Rated Voltage Specifications | DC48/-AC220V | DC48-AC110V |
| Operating Voltage Range(Normal Operating Battery Voltage) | 40V-64V (DC48V) | |
| Low Voltage Alarm(alarm to alert users when battery’s voltage is over low) | 42.0Vdc ± 1.2Vdc (48V) | |
| Low Voltage Shut off (shut off when battery’s voltage is over low) | 40.0Vdc ± 1.2Vdc (48V) | |
| Low Voltage Recovery (Automatic Boot when battery’s voltage returns to normal) | 48.0Vdc ± 0.3Vdc (48V) | |
| High Voltage Alarm and shut off ( alarms and shut off when the battery’s voltage is over high) | 64Vdc ± 1.2Vdc (48V) | |
| High Voltage Recovery (Automatic boot when battery’s voltage returns to normal) | 62.0Vdc ± 1.2Vdc (48V) | |
| orerter Efficiency | ≥90% | |
| DC-priority type, battery low voltage conversion point when there is utility electricity bypass ( battery voltage is lower than this, turn to utility electricity to supply) | 44Vdc ± 1.2Vdc (48V) | |
| DC-priority type, after turning to utility electricity to supply, the battery low voltage recovery point (when the battery’s voltage is higher than this, turn to battery to supply electricity) | 54.0Vdc ± 1.2Vdc (48V) | |
| AC Input Specifications | ||
| Rated Voltage Specifications | 220VAC System | 110VAC System |
| Input Voltage Waveform | Sine wave (utility electricity or generator) | Sine wave (utility electricity or generator) |
| Rated Input Voltage | 220Vac/230Vac/240Vac | 110Vac/120Vac/130Vac |
| Low Voltage Shut off | 180Vac±4% | 85Vac±4% |
| Low Voltage Recovery | 195Vac ±4% | 90Vac ±4% |
| High Voltage Shut off | 260Vac±4% | 135Vac±4% |
| High Voltage Recovery | 255Vac±4% | 130Vac±4% |
| Utility Electricity Charging rule | Three Stages: | |
| Constant current charging (constant stage)→constant voltage(constant voltage stage)→float (constant voltage stage) | ||
| Utility Electricity Supply Efficiency | ≥98% | |
| Conversion Time (AC to DC) | <4ms | |
| Conversion Time (DC to AC) | <8ms | |
| AC output specifications | ||
| Rated output voltage (V) | 220Vac/230Vac/240Vac | 110Vac/120Vac/130Vac |
| Output Voltage Range | ±10% rms | |
| Rated output frequency(Hz) | 50Hz ± 0.3Hz/60Hz ± 0.3Hz(Optional) | |
| Power Factor | 0.9 | |
| Output Waveform | Pure sine wave | |
| Waveform distortion rate( THD ) | ≤3% ( Linear load ) | |
| Dynamic Response( 0~100% ) | 5% | |
| Peak Factor ( CF ) | 3:1 | |
| Overload Protection (SMPS load) | 110% 125% | |
| Other notes | ||
| Continuous operation time | Continuous operation | |
| Normal Boot no-load Depletion | ≤Rated Power×2.5% | |
| No-load Depletion of energy-saving mode | ≤6W | |
| Safety Certification | CE(EN62040-1) EMC :EN62040-2, C2 | |
| Communication Interface | RS232 / (Customizable) | |
| Cooling | Temperature-controlled variable speed fan cooling (Ventilation condition) | |
| Noise( dB,1 meter ) | <60dB | |
| Ambient temperature ( ºC) | -10~+45 | |
| Storage Temperature( ºC) | -20~+55 | |
| Using Environment Humidity | 0-95% relative humidity(No condensation) | |
| Altitude( m ) | ≤5000( More than 1000 m, derating ) | |
| Display Way | LED Indicator +LCD Display | |
| Alarm Way | Buzzer sounds alarm | |
| Protection Functions | Low voltage protection, high voltage protection, high temperature protection, short circuit protection, leakage protection, overcurrent protection, overload protection, low recovery, high recovery, intelligent temperature control, solid barrier alarm | |
| Protection Level | IP20 / Customizable | |
