    Outdoor Waterproof 4G 5G 48VDC 1500W to 2000W Switchable Power Supply AC-DC 48v 30a Output for Industrial Holding Pole

    EVS-1500W
    minimum order:
    1 piece
    Quantity:
    $95.00 - $115.00 / piece
    Contact Now
    add to cart
    • Input Voltage:220 V
    • Output Current:30A
    • Output Voltage:48V
    • Model Number:EVS-1500W
    • Brand Name:OEM ODM
    • Place of Origin:Guangdong, China
    • Application:Industry, Machines, Industrial Equipment, Battery Charging, Telecom base stations
    • Efficiency:0.94
    • Output Frequency:50/60Hz
    • Output Type:Single
    • Protection:Overcurrent Protection, Overvoltage Protection, Over Temperature Protection, Over Power Protection, Overloading Protection
    • Type:AC-DC, DC-DC, Outdoor power Supply
    • Function:Battery charging
    • Logo:Can be design according to customer
    • Condutor:Rectifier Module
    • Installation method:Wall mounted ,Holding pole
    • Optional Features:modbus communication

    Product Category




    product details








    Our products







    Waterproof outdoor power cabinet 4G 5G 48vdc 1500W 2000W 3000W Switch Power Supply


    Features with the following specifications:





    EVS-1000W is a kind of AC / DC (or DC / DC) high-power power supply with single output.





    Outdoor power supply adopts the latest circuit design, with compact structure and reliable performance.





    Outdoor power supply  has high stability precision and high output efficiency. Wide range of input voltage, input with over-voltage protection, output with short-circuit protection, over-current protection and over temperature protection, cooling system adopts natural heat dissipation. The whole power supply is designed in strict accordance with the requirements of safety regulations, and meets the requirements of information technology equipment safety standards.





    EVS-1500w outdoor power supply has the following characteristics:


    it has d-level lightning protection capability, outdoor high dust-proof and waterproof design, protection grade IP65, direct contact heat dissipation at the bottom, metal shell, power shell and cable connector need to be equipped with anti off screw, supporting four installation methods of wall hanging, holding pole, steel belt holding pole and landing.








    1,Rectifier module adopts active power factor compensation technology, power factor up to 0.99.
    2,AC input voltage of normal operating range as wide as 90~280Vac/120~400Vdc
    3,Rectifier modules adopts full bridge soft switching technology, efficiency can reach above 94%.












































    Outdoor power Supply performance index input


    Parameter


    Min.


    Rated


    Max.


    Unit


    Note


    Rated working voltage range


    110/220


    Vac



    Input voltage range


    90


    220


    290


    Vac


    Three-phase five-wire input phase to phase 380V / relative zero line 220VAC


    Output voltage range


    42


    48


    58


    Vdc
