48Vdc 3000W Single Output Din Rail Rectifier Module Switching Power Supply for Communication Base Station 50A Current 500W Power

RM4850

minimum order:

1 piece

Quantity:

$100.00 - $149.00 / piece

Contact Now

add to cart

Application:laboratory, Industry
Efficiency:0.92
Protection:Over Temperature Protection, Overvoltage protection
Place of Origin:Guangdong, China
Brand Name:OEM ODM
Model Number:RM4850
Output Type:Single Phase
Input Voltage:80-300vac
Output Voltage:48vdc
Output Current:50A
type:DC-DC, AD-DC
Type:telecom rectifier for switching power supply
Function:Telecom base stations
Compatible Brand:Emerson, Huawei, ZTE,vapel, Eltek
Logo:Can be design according to customer
Condutor:Rectifier Module
Colors:RAL7035 or RAL9004

Our products

3000w 48v rectifier module Specification:

1. Standard installation structure design, strong versatility

2.Rectifier module adopts active power factor compensation technology, power factor up to 0.99.

3.Rectifier module operating temperature range -40 ~ +75 °C

4.Hot-swappable technology, convenient installation and maintenance

5. Compact power supply structure saves space and saves installation costs

6.High efficiency rectifier module efficiency over 96%, energy saving and emission reduction

7.Perfect module sleep function, further improve system efficiency

8. Intelligent battery management and battery protection to extend battery life,Compatibility of lead-acid and lithium batteries

9.Support Module anti-theft,Communication input detection,Environmental monitoring, remote management through dry contacts, serial ports, or RS485/Modbus/SNMP network interfaces

3000w 48v rectifier module performance index input
Parameter	Min.	Rated	Max.	Unit	Note
Rated working voltage range		110/220		Vac
Input voltage range	90	220	290	Vac	Three-phase five-wire input phase to phase 380V / relative zero line 220VAC
Output voltage range	48	53.5	58	Vdc
