220V AC 48V DC Converter 1500W Single Output LED Lithium Battery Charger 30A 1A for Industrial Applications AC-DC Power Supplies

EVS4830A

minimum order:

1 piece

Quantity:

$95.00 - $115.00 / piece

Contact Now

add to cart

Input Voltage:90-290VAC/100-400VDC
Output Current:30A
Output Voltage:48Vdc
Model Number:EVS4830A
Brand Name:EVS
Place of Origin:Guangdong, China
Application:Industry, Laboratory, Industrial Equipment
Efficiency:95%
Output Frequency:45-65HZ
Output Type:Single
Protection:Over Power Protection, Overloading Protection, Over Temperature Protection, Overvoltage Protection, Overcurrent Protection
Type:AC-DC, DC-DC
Output voltage range:54VDC,customizable
Output current range:1A~30.0A,customizable
Output efficiency:92% full load
Stable voltage accuracy:≤ ± 1%
Load adjustment rate:≤ ± 0.6%
Source adjustment rate:≤ ± 0.5%

product details

230vac to 48v dc power supply with multiple outputs, and the entire power supply adopts the latest circuit design, with a compact structure and reliable performance.

1.High precision of whole machine voltage stabilization
2.High output efficiency
3.Wide input voltage range
4.Input has overvoltage and undervoltage protection
5.The output has overcurrent protection, overvoltage protection, and short circuit protection

220v Ac to 48v Dc Converter environment condition
1. Working temperature: -40 ℃~+55 ℃
2. Storage temperature: -40 ℃~+80 ℃
3. Relative humidity: 10% to 90%
4. Altitude: ≤ 3000m
5. Atmospheric pressure: 70-106KPa
6. Cooling method: forced cooling by fan

220v Ac to 48v Dc Converter Technical Parameter

Input voltage range: 90-285Vac
Input voltage frequency range: 47-63Hz
Input impulse current: 50A
Input protection: 10A

Output voltage: 54Vdc

Output power: 1800W
Output voltage range: -43V~-59Vdc
Output current range: 0.1A~30.0A
Stable voltage accuracy: ≤ ± 1%
Load adjustment rate: ≤ ± 0.6%
Source adjustment rate: ≤ ± 0.5%
Ripple: ≤ 200mV
Output efficiency: 92% full load

Various input and output voltage specifications can be customized, such as

12VDC/24VDC/36VDC/48VDC/50VDC/60VDC/72VDC/96VDC/120VDC/240VDC
