CE RoHS Approved DC Power Unit 24V 20A Single Output DC-DC Switching Power Supply Industrial Use 500W Output Power 110V/220V

EVS 24250E

minimum order:

1 piece

Quantity:

$500.00 - $680.00 / piece

Contact Now

add to cart

Application:Industry, for Telecom Equipment,Battery Charging
Efficiency:0.95, 92%
Protection:Overcurrent Protection
Place of Origin:Guangdong, China, Shenzhen, China (Mainland)
Brand Name:EVS, EVS Industrial switching power supply
Model Number:EVS 24250E
Output Type:Single Phase
Input Voltage:220V, 90~280VAC
Output Voltage:24V
Output Current:200A
type:AC-DC
Output Power:10000W
Type:DC Power Unit CE RoHS approved Single Output 24v 200a power supply
Use in:exchange room, server room,base station,data communication
Size:482*300*266mm

Product Description

DC Power Unit CE RoHS approved Single Output switching power supply 24v 20a1,Features
1,switching power supply 24v 20a adopts active power factor compensation technology, power factor up to 0.99.
2,AC input voltage of normal operating range as wide as 90 ~ 290V.
3,Rectifier modules adopts full bridge soft switching technology, efficiency can reach above 92%.
4,Perfect battery management: low voltage load disconnect (LVLD) and low voltage battery disconnect (LVBD) to achieve temperature compensation, automatic float control, automatic voltage regulator, battery capacity calculation, online battery test function.
5,Rectifier module adopts no damage hot insert and pull technology, replacement time less than 1min.
6,Network design, providing a variety of communication interfaces (for example: RS485, dry contact), flexible networking can achieve local and remote monitoring, unattended. Perfect AC and DC side lightning protection design used in multi thunderstorm area.
7,Complete fault protection, fault alarm function.
8,Comprehensive operation and maintenance, and can be mounted against the wall, saving space effectively.
9,Ultra-low radiation. Adopt advanced electromagnetic compatibility design, the rectifier module can meet requirements for conducted and radiated interference of"the communication power equipment electromagnetic compatibility Limits and methods of measurement"( People's Republic of China telecommunications industry standard YD/T983).
10,Safe and reliable. System design in full compliance with safety standards EN60950 and GB4943.

2,Power System Configuration

Optional	Rectifier	Module number	Distribution	Monitoring	Remark
Configuration	50A	1-4pcs	AC distribution: AC220Vinput, Load output:50A-200A	Monitor	Specific index refer to module specification

3, Power system work principle

4, DC Power Unit CE RoHS approved Single Output switching power supply 24v 20a

Power system performance index

Input
Parameter	Min.	Rated	Max.	Unit	Note
Rated working voltage range		110/220		Vac
Input voltage range	90	220	290	Vac	Three-phase five-wire input phase to phase 380V / relative zero line 220VAC
Input frequency	43	50	67	Hz
Battery input	21	24	29	Vdc	Battery pack’s positive and negative in parallel with DC output of rectifier module (polarity consistent)

Output
Parameter	Min.	Rated	Max.	Unit	Note
Output voltage range	20	24	30	Vdc
Output current range (max.current)	0		250	A	Input 170 ~ 285VAC, when the input voltage is below 170VAC, output at derating manner.
Regulation accuracy			±1	%
Load regulation			±1	%
Source regulation			±1	%
Current sharing regulation			±5	%
Ripple ( peak – peak value)			200	mv	Network 20MHztesting.
Output efficiency	91	93		%	220Vac Input
