    Dc 300V 400V 500V 600V Output 5A AC DC Charging Power Supply for Energy Storage System

    EVS500-3200
    minimum order:
    1 piece
    Quantity:
    $150.00 - $220.00 / piece
    Contact Now
    add to cart
    • Place of Origin:Guangdong, China
    • Brand Name:OEM ODM
    • Model Number:EVS500-3200
    • Output Type:Single Phase
    • Input Voltage:220V
    • Output Voltage:500VDC
    • Output Frequency:50/60Hz
    • Output Current:5A
    • type:AC-DC
    • Type:EV rectifier
    • Function:Telecom base stations
    • Condutor:250-750v dc power supply
    • Source effect:± 0.1%
    • Load effect:± 0.4%
    • Voltage stabilization accuracy:± 0.1%
    • Minimum current:0A
    • Maximum current:5A

    Our products

    Evspower 500v dc power supply Features:
    1. Compact structure
    2. High efficiency more than 94%.
    3. Power factor correction ≥0.99
    4. Perfect protection function,input over/under voltage protection, output over voltage protection, output over current protection, output short circuit protection,over temperature alarm and protection.
    5. Customized output interface available,with communication port RS485
    6. Paralleled work is available via current sharing bus
    7. THD≤5%

    60v dc power supply Application:
    1. Energy Storage System
    2. Battery charger
    3. Server
    4. Indoor wireless network


    Power supply performance index input

    Parameter

    Min.

    Rated

    Max.

    Unit

    Note

    Rated working voltage range

    110/220

    Vac

    Input voltage range

    90

    220

    264

    Vac

    Input frequency

    45

    50

    65

    Hz

    Power Factor
    		≥0.99@220VAC

    Power supply performance index output

    Parameter

    Min.

    Rated

    Max.

    Unit

    Note

    Output voltage range

    250
    		500750
    Vdc


    Output current range


    0
    		5
    A
    		230V±10V


    Current Sharing

    		±5%



    Output Protection

    		Over voltage protection,Under voltage protectionOver temperature protection,Hot-swappable Internal failure isolated diode Short circuit protection
