RM483000LV 3KW 48V 50A Modular Rectifier 3000W Single Output Power 48V

RM483000LV

minimum order:

1 piece

Quantity:

$130.00 - $130.00 / piece

Contact Now

add to cart

Place of Origin:Guangdong, China
Brand Name:OEM ODM
Model Number:EV4850S
Output Type:Single Phase
Input Voltage:90-280VAC
Output Voltage:42-58V
Output Frequency:50/60Hz
Output Current:50A
Type:telecom rectifier for switching power supply
Logo:Can be design according to customer
Function:Telecom base stations
Condutor:Rectifier Module
Warranty:Within One Year
Output Power:3000W
type:AD-DC

Our products

Features with the following specifications:

R4850 is a digital rectifier that converts the 85~300VAC to 53.5 VDC and possesses the characters of high efficiency, high power density, walk-in start, hot-plug, complete protection, and low noise. The rectifier adopts the latest power monitoring technology, implements the function of monitoring the states of loads and the rectifier status in real time. The output voltage of the rectifier can be adjusted through the hos

48v 50a modular rectifier index input
Parameter	Min.	Rated	Max.	Unit	Note
Rated working voltage range		110/220		Vac
Input voltage range	80	230	300	Vac	Three-phase five-wire input phase to phase 380V / relative zero line 220VAC
Input frequency	43	50	67	Hz

48v 50a modular rectifier index output
Parameter	Min.	Rated	Max.	Unit	Note
Output voltage range	42	53.5	58	Vdc
Output current range	1		50	A	input 170 ~ 285VAC, when the input voltage is below 170VAC, output at derating manner.
