    Single Phase 1KVA 800W Pure Sine Wave Inverter 48V DC to 220V AC Converter 50Hz Output Frequency Rack Mount Telecom Inverter

    EVS-A3-1048R
    minimum order:
    1 set
    Quantity:
    $180.00 - $220.00 / set
    Contact Now
    add to cart
    • Output Current:4.5A
    • Output Frequency:50 Hz, 60 Hz
    • Phase:Single Phase
    • Type:DC/AC Inverters
    • Model Number:EVS-A3-1048R
    • Brand Name:EVS
    • Place of Origin:Guangdong, China
    • Application:Industrial, Telecommunications
    • Efficiency:95%
    • Network:SDK
    • Output Type:SINGLE
    • Size:19''2U
    • Weight:10kg
    Product Description

    -


    Specification

    Description
    1.True sine wave output (T.H.D < 3%);
    2.Lcd display data information;
    3.Standard 19” Rack mount case;
    4.Routes Dry contact for system (DC input fault, AC input fault, overload information, by-pass information and output fault)

    Function
    1.RS232 and RS485 & Modbus communication Port;
    2.Power-on self-test, Soft output start;
    3.Audible and visual alarm;
    4.Record the historical alarm message and can be queried;
    5.Real-time monitoring of the system operating status;

    Feature
    1.Auto switch function: DC to AC, AC bypass, less than 5ms;
    2.By-pass AC 220V input filtering;
    3.Start auto restart while Ac or Dc is recovering;
    4.Automatic start temperature control fan
    5.Build in voltage regulator Stabilize AC voltage;
    6.Protection :Short load protection, over load protection, battery over/under voltage protection, over current, over temperature;
    7.Unattended operation: the system switches automatically to provide AC Power to the load between the DC input and AC input.


    Model (EVS-A3)

    1000

    2000

    3000

    4000

    5000

    6000

    8000

    10000

    12000

    Rate capacity(VA)

    1KW/

    1.25KVA

    2KW/

    2.5KVA

    3KW/

    3.75KVA

    4KW/5KVA

    5KW/

    6.25KVA

    6KW/

    7.5KVA

    8KW/

    10KVA

    10KW/

    12.5KVA

    12KW/

    15KVA

    DC input

    Input voltage

    DC24V; DC48V; DC110VDC220V;

    Range voltage

    DC20-32V;DC30-48V;DC90-144V;DC180-288V;

    Communication input

    Rated AC input voltage

    AC220V/AC110V (mains power/generator)

    AC input range

    170-280Vac (UPS mode) factory default; 90-280Vac (APL electrical mode)

    AC input frequency

    50HZ/60HZ (optional in the backend)

    UPS conversion time

    <5ms (UPS mode) factory default; <13ms (electrical appliance mode)

    AC Output

    AC output voltage

    220/230/240Vac±3% optional

    AC output frequency

    50±1HZ/60±1HZ (optional in the backend)

    Output waveform

    Pure sine wave (full voltage range)

    Waveform distortion rate

    ≤3% (linear load)

    Inverter peak efficiency

    95%

    Dynamic response

    (0~100%)≤5%

    Power factor

    >0.9

    Size(mm)

    2U/19inch

    482*414*88

    2U/19inch

    482*445*88

    3U/19inch

    482*445*132

    Weight (kg)

    9

    9

    10

    12

    12

    12

    14

    15

    16

    Communication method

    Standard configuration: RS485 (communication modes such as RS232/WIFI/GPRS/CAN can be customized)

    protection grade

    IP20 / Customizable

    Standard configuration instructions

    1 AC input, 1 DC input, 1 AC output, RS485 interface

    Optional Unit

    1: Fault dry contact; 2: External switch box; 3: External display box; 4: RS232; 5: WIFI module; 6:GPRS module; 7: Ethernet module; 8: CAN communication; 9: Bypass input;

    Others

    DC24V/48V/110V/220V models are standard products, while DC12/36/60/72/96/192/240V models are EVSPOWER customized products


    Selling Point


    1.The product is the evspower A3 48v dc to ac power inverter, a high-quality and reliable solution for telecommunication applications in need of 220vac single-phase power. Remarkable features like its compact size (19'' 2U), easy installation, and efficient operation make it a convenient choice for installation in confined spaces. This versatile inverter delivers a steady output of 1KVA, providing enough power to meet diverse telecommunication needs. Add to it its compatibility with diverse voltage sources, excellent retention of the original waveform, and its variable control of load current to guarantee optimal performance.

    2.The evspower 48v dc to ac power inverter with an impressive list of features including single-phase, single frequency output (50Hz / 60Hz), making it suitable for use in both industrial and telecommunications environments where electricity supply commonly falls within these parameters.

    3.Specifically designed for telecom use, the inverter is built with rigorous standards and safety mechanisms to protect against both over-voltage and over-current conditions, ensuring reliability and longevity of the equipment. It comes with a high output of 4.5A and supports a wide range of input voltage (24-48vdc), providing a flexible and versatile power solution for different voltage requirements.

    4.As a jetpower branded, it's backed up by the manufacturer's commitment

    5.Lastly, each inverter undergoes strict quality control before leaving the manufacturing facility, ensuring that only top-quality products reach the hands of customers. With its compatibility in different industries, easy installation process, and robust design, the evspower 48v dc to ac power inverter 48v dc to 220v ac Telecommunication Power Inverter is an excellent investment for any organization in need of a reliable 220vac single-phase power source.
